Description
RCS-095 – Connector Set, Metri-Pack 280 Sealed FVMQ (Gas + Ethanol safe), 2F
This connector set is supplied with special Fluorosilicone (FVMQ) seals specially molded by Racetronix. Unlike silicone seals that disintegrate in fuel and solvents , these FVMQ seals are resistant to solvents and fuels so they are safe to use in your gas tank.
This weatherproof connector set is recommended for the following medium-current applications:
Fuel Pumps
FOR USE WITH FUELS. PLEASE SEE RCS-057 FOR STANDARD NON-FUEL APPLICATIONS
SPECIFICATIONS (KIT):
WIRE O.D. (mm): 2.03-4.30mm
WIRE GAUGE (AWG): 10, 12, 14
KIT INCLUDES:
1 x Female Connector Body with FVMQ seal (installed)
3 x FVMQ Cable Seals
3 x Female Terminals 14-10 Ga. (1 spare)
1 x Terminal Lock (Blue)
NOTE: Proper B-type crimpers and soldering equipment are recommended to properly assemble this connector set.
CONNECTOR SPECIFICATIONS:
CURRENT RANGE (AMPS): 0-30
TEMP RANGE °C: -40 to 125
RESISTANCE:
VOLTAGE DROP:
CENTER LINE SPACING (mm): 7.7
BLADE WIDTH (mm): 2.8
